| SPECIFICATIONS | |
|---|---|
| Architecture | NVIDIA Ampere Architecture |
| Process Size | 8nm |
| Transistors | 13.25 Billion |
| Die Size | 276 mm2 |
| CUDA Cores | 3328 |
| Tensor Cores | 104 |
| RT Cores | 26 |
| Peak FP32 Performance | 7.99 TFLOPS |
| RT Core Performance | 15.6 TFLOPS |
| Tensor Core Performance | 63.9 TFLOPS |
| GPU Memory | 6 GB GDDR6 ECC |
| GPU Memory Clock | 6001 MHz |
| Memory Interface | 192-bit |
| Memory Bandwidth | 288 GB/sec |
| Maximum Power Consumption | |
| System Interface | PCI Express 4.0 x16 |
| Display Connectors | 4x mDP Latching |
| Form Factor |
2.713" H x 6.6" Low Profile | Dual Slot |
| Thermal Solution | Active Fansink |
| Max Digital Resolution | 2x 7680 x 4320 at 60 Hz |
| Max Displays |
4x at 5K | 5120 x 2880 at 60 Hz |
| HDR Support | Yes |
| AR | VR | XR Ready | Yes |
| Quad Buffered Stereo | Yes |
| Hardware Accelerated BVH | Yes |
| NVIDIA DLSS | Yes |
| NVIDIA Mosaic, Warp and Blend | Yes |
| NVIDIA RTX Experience | Yes |
| NVIDIA RTX Desktop Manager | Yes |
| NVIDIA Broadcast Application | Yes |
| NVENC | NVDEC | 1x H.264 and HVEC Encoders 1x Decode Engine |
| Graphics APIs |
DirectX 12.07, Shader Model 5.17, Open GL 4.68, Vulkan 1.2 |
| Compute APIs | CUDA, DirectCompute, Open CL |
| AVAILABLE ACCESSORIES | |
|---|---|
| MDP-HDMI-FOUR-PCK | connects the NVIDIA RTX A2000 (or RTX A2000 12GB) to HDMI displays at resolutions up to 4K with PNY Part Number MDP-HDMI-FOUR-PCK. The four included DisplayPort to HDMI adapters are recommended by NVIDIA, provide outstanding image quality, and are built to professional standards. |
| MDP-HDMI-SINGLE-PCK | connects the NVIDIA RTX A2000 12GB (or RTX A2000) to an HDMI display at resolutions up to 4K with PNY Part Number MDP-HDMI-SINGLE-PCK. The included DisplayPort to HDMI adapter is recommended by NVIDIA, provides outstanding image quality, and is built to professional standards. |
| SUPPORTED PLATFORMS | |
|---|---|
| Microsoft Windows 10 (64-bit) Red Hat Enterprise Linux 7.x SUSE Linux Enterprise Desktop 15.x OpenSuse 15 Fedora 31 Ubuntu 18.04 FreeBSD 11.x Solaris 11 |
| MINIMUM SYSTEM HARDWARE REQUIREMENTS | |
|---|---|
| Intel Core i5, i7, i9, or Xeon processor or later AMD Ryzen or Epyc class processor or later PCI Express 4.0 x16 (preferred) expansion slot System memory greater than or equal to GPU memory, twice the GPU memory recommended Internet connection for driver installation DisplayPort 1.4a (preferred), HDMI, or DVI compatible display(s) |
| PACKAGE CONTAINS | |
|---|---|
| NVIDIA RTX A2000 Pro Graphics Board with ATX Bracket Unattached full-height (ATX) bracket NVIDIA RTX Quick Start Guide NVIDIA RTX Support Guide 1 latching mDP to DP adapter |
